The Ultimate 1 Collector :: Industrial Wet-Type Dust Collector

LOW OPERATING COST & MINIMAL MAINTENANCE

MS TYPE - STYLE B
The MS Type Style B uses a conical hopper and drain valves for sludge disposal. This system is ideal in applications where the discharged sludge or slurry can be taken to a settling tank or drained continuously (where water supply conditions permit). Also, in applications where the dust presents no caking or settling problems, it is possible and often economical to periodically clean the MS Type Style B system manually.

Applications
Ultimate I Industrial Wet-Type Dust Collectors are designed to produce clean air economically for all industry. The "Ultimate I" is extremely effective on both light and heavy loads of a vary wide range of dust and fumes. Examples are processing and finishing of aluminum, magnesium, titanium, stainless steel, plasma cutting, plasma hot metal spraying, laser cutting, melting furnaces, removing dust and odour from green sand mold, cooling and shake out operations, removing dust from shot blast operations, grinding and buffing ect. Anywhere that dust is a problem there is an "Ultimate" solution.

How the Unit works
The Ultimate I Industrial Wet-Type Dust Collector works this way. Contaminated air is drawn into the unit through a tapered scrubber and forced down through a venture, deep into the water, where the air is released. The water acts as a separator, and many of the dust particles fall to the bottom of the unit immediately. Those particles that manage to escape this first stage of cleansing, are forced through thick curtains of water, and are repeatedly deflected by a series of thick curtains of baffles, into the water turbulence, separating the remaining dust from the air. The airflow creates a circulation in the water that simultaneously removes dust particles from the water and prevents stagnation of the water. The moist air is drawn through the unit by an internally fitted fan, passes through the mist eliminators, where the moisture is removed from the clean air. The clean air is then returned to the workplace. The dust which has settled to the bottom of the unit will be removed through the sludge drain valves, rake out, hopper or drag bar conveyor.

Standard units are available in capacities ranging from 400 to 50,000 C.F.M.

Features of this Unit

Industrial Wet Scrubber Data Chart (PDF: 55Kb)
