Source Capture Arms
Fume Arms Technical Data - Mounting flange


Fume Arms Overview

Standard models table

Airflow diagrams

Flange dimensions


Dimensions table (imperial)
Arm diam. n d
[mm] 		D1
[mm] 		D2
[mm] 		D3
[mm] 		h
[mm]

75

4

6.5

72

112

125

5

100

4

6.5

94

134

148

5

125

6

7

120

165

183

7

160

6

7

153

195

220

7

200

8

9

198

246

275

9



Dimensions table (imperial)
Arm diam. n d
[in.] 		D1
[in.] 		D2
[in.] 		D3
[in.] 		h
[in.]

3"

4

.26

2.85

.4.41

4.92

.20

4"

4

.26

3.78

5.28

5.83

.20

5"

6

.28

4.72

6.49

7.20

.26

6"

6

.28

6.02

7.68

8.66

.26

8"

8

.35

7.79

9.68

10.83

.35
