Explosion Relief Vents

• SEV-ST1-24R00000:  Exp Vent - 24" Round Separator (ST1) (200 Kst / 8.7 Pred) (500 CFM Max)
• SEV-ST2-24R00000:  Exp Vent - 24" Round Separator (ST2) (300 Kst / 8.7 Pred) (500 CFM Max)
• SEV-ST2-30R00000:  Exp Vent - 30" Round Separator (ST1 & ST2) (200 & 300 Kst / 8.7 Pred) (1000 CFM Max)
• SEV-ST1-38R00000:  Exp Vent - 38" Round Separator (ST1) (200 Kst / 8.7 Pred) (1400 CFM Max)
• SEV-ST2-38R00000:  Exp Vent - 38" Round Separator (ST2) (300 Kst / 8.7 Pred) (1400 CFM Max)
• SEV-ST1-42R00000:  Exp Vent - 42" Round Separator (ST1) (200 Kst / 8.7 Pred) (1500 CFM Max)
•  SEV-ST2-42R00000:  Exp Vent - 42" Round Separator (ST2) (300 Kst / 8.7 Pred) (1500 CFM Max)
• SEV-ST1-48R00000:  Exp Vent - 48" Round Separator (ST1) (200 Kst / 8.7 Pred) (2000 CFM Max)
•  SEV-ST2-48R00000:  Exp Vent - 48" Round Separator (ST2) (300 Kst / 8.7 Pred) (2000 CFM Max)
• SEV-ST1-54R00000:  Exp Vent - 54" Round Separator (ST1) (200 Kst / 6.5 Pred) (2700 CFM Max)
• SEV-ST2-54R00000:  Exp Vent - 54" Round Separator (ST2) (300 Kst / 6.5 Pred) (2700 CFM Max)
• SEV-ST1-66R00000:  Exp Vent - 66" Round Separator (ST1) (200 Kst / 6.5 Pred) (4200 CFM Max)
• SEV-ST2-66R00000:  Exp Vent - 66" Round Separator (ST2) (300 Kst / 6.5 Pred) (4200 CFM Max)
• SEV-ST1-72R00000:  Exp Vent - 72" Round Separator (ST1) (200 Kst / 6.5 Pred) (4600 CFM Max)
• SEV-ST2-72R00000:  Exp Vent - 72" Round Separator (ST2) (300 Kst / 6.5 Pred) (4600 CFM Max)

NOTE:  The above design calculations are provided for equipment selection guidance only.  Final design criteria related to explosion relief vents must be reviewed by Eurovac engineering prior to final selection and release.

NOTE 2:  Eurovac systems can be suited to accommodate ST3 Class 3 Dusts after site specific engineering review and design

• Relief Vent w/ Burst Indicator & 10' extension cable (Burst indicator will shut down system)
• Separator fabricated with heavier gauge steel
• Modification to separator to accomodate relief vent
• Modification to main control panel to accomodate burst indicator
• Dome separator top (for added separator strength)

• Deflector Plates:  Designed to deflect the flame ball exhaust and reduce the safety area near explosion vents.  Deflector plates are mounted to the outside of a collector in front of the explosion relief vent.
