Name: Flameless Relief Valves
Brand: Eurovac
Availability: InStock

Flameless Relief Valves

Product Overview

Many dust collection systems are located inside a building or another area where standard explosion venting cannot safely be employed. For these applications, flameless explosion vents may be the best protection solution. The flameless vent consists of a venting device with an integrated flame arrester. When an explosion occurs, the venting device opens and directs the vented explosion through the flame arrester, where gases are cooled as they pass through the flame arrester material thus preventing flames from being expelled to the surrounding areas.

Product Details

Comprehensive information about this product

Part Numbers:

UPG-EXP-24FVSIDI: Flameless Exp Valve - 24" Round Separator
UPG-EXP-30FVSIDI: Flameless Exp Valve - 30" Round Separator
UPG-EXP-38FVSIDI: Flameless Exp Valve - 38" Round Separator
UPG-EXP-42FVSIDI: Flameless Exp Valve - 42" Round Separator
UPG-EXP-48FVSIDE: Flameless Exp Valve - 48" Round Separator
UPG-EXP-54FVSIDE: Flameless Exp Valve - 54" Round Separator
UPG-EXP-66FVSIDE: Flameless Exp Valve - 66" Round Separator

NOTE: The above design calculations are provided for equipment selection guidance only. Final design criteria related to flameless relief valves must be reviewed by Eurovac engineering prior to final selection and release.

Equipment Specs:

Separator fabricated with heavier gauge steel
Modification to separator to accommodate flameless relief valve
Dome separator top (for added separator strength)

Optional Additions

The integrated electronic controls opening detection can be used to keep plant personnel informed of the status of the system.
