EI – Wet Mix Dust Collectors – Product

Product Overview

EI Wet Mix Dust Collectors offer high vacuum performance for one to six technicians operating depending on what type of source capture tools are being used or whether they are vacuum housekeeping. Wet Mix Dust Collectors remove explosive dust by driving the particulate deep into the water via a venturi. Dust then passes through a set of baffles (entrapping the dust in water) which settles to the bottom of the collector. All systems meet NFPA and OSHA guidelines.

Product Details

Comprehensive information about this product

Application:

1 to 3 Tech Housekeeping Vacuum System
1 to 3 Tech Grinder Vacuum System
3 to 6 Tech Orbital Sander Vacuum System

Part Numbers:

EIP-M05-1800410B: 5HP System
EIP-M10-1800410B: 10HP System
EIP-M15-2400410B: 15HP System

Equipment Specs:

Construction: Fully welded stainless steel body with standard steel blower housing cabinet
Finish: Texture Blue powder coated painted finish
Blower: Regenerative Blower set to run for 20,000+ hours of continuous use
Filtration: Initial venturi entry (for deep penetration of dust into the water), secondary baffles (to help knock water/dust back down) and final mesh mist eliminator (99% efficient to 5 microns)
Manual Water Intake Port
Relief Valve: Exhausts hydrogen gas build-up in an aluminum application, when system is shut down
Automatic Low Water Shut Down: Unit will not operate if water is not set to proper levels
Time Delay: A time delay switch prevents the start of the dust-producing process until the collector is in complete operation
Off Delay: An off delay timer switch allows the system to run for a set amount of time once the dust-producing process has stopped, ensuring all dust in the hose reaches the collector.
Inlets: 3HP to 10HP: Qty 3: 1-1/2″ Inlets
15HP: Qty 4: 1-1/2″ Inlets
