Product Details
Comprehensive information about this product
Application:
- 1 Tech Source Capture Welding System
Part Numbers:
- POR-P46-B02F0005
Equipment Specs:
- Construction: Fully welded steel construction
- Finished: Texture Black powder coated painted finish
- Blower: QTY 2 – 2.3HP Brush Motors (4000 Hrs Intermitent Duty) – 1300 watt motors
- Filtration: Cyclonic filter separator & final nanofiber filter (99.93% at 3 microns or larger)
- Controls (On/Off): 2 Position Switch
- Timer: If system is run for 40 minutes continuously, it will automatically shut off
- Electrical: 1 Phase 60 Hertz 220/120 (4 wire: 2 Hot, 1 Neutral & 1 Ground). NEMA #L1420P plug provided
- Canister: 5 Gallon
- Inlet: 2″
System Performance:
- 100 CFM at 103″ WG
- Vacuum – 137″WC
- Flow – 224 CFM
Includes
- 2″ x 17′ Hose
- Hose Hanger
