Product Details
Comprehensive information about this product
Part Numbers (Dust Applications):
- SYS-BIF-10046030: 1HP BI Fan
- SYS-BIF-2B046030: 2HP BI Fan
- SYS-BIF-30046030: 3HP BI Fan
- SYS-BIF-50046030: 5HP BI Fan
Equipment Specs:
- Construction: Fully welded steel construction
- Finish: Texture blue powder coated painted finish
- Impeller: Constructed with backward incline blades of heavy cast aluminum, dynamically balanced and designed for efficient operation
- Inlet/Outlet: Inlet includes companion flange. Both inlet and outlet have a protective debris screen
- Electrical: 208-240, 460 and 575 volts. 3 phase, 60 hertz Premium Efficiency TEFC Motor. 1HP & 2HP available with 110-220 volts, 1 phase, 60 hertz.
Fan Performance:
- Pressure Range – 4″ to 6” WC
- Flow Range – 450 to 950 CFM
Optional Additions
- Horizontal Mount Base
- Wall Mount Bracket
- Fan Weather Cover
- Backdraft Damper
- Roof or Wall Exhaust Vents
- Silencers and Exhaust Caps
- Sound Cabinets
- Drain Port
