Product Details
Comprehensive information about this product
Part Numbers:
- SYS-WEL-DP606040: 6” x 10’ (6’ & 4’) Double Pivot Extension Boom
- SYS-WEL-DP610050: 6” x 15’ (10’ & 5’) Double Pivot Extension Boom
- SYS-WEL-DP620000: 6” x 20’ (13’ & 7’) Double Pivot Extension Boom
Equipment Specs:
- Construction: Fully welded steel construction
- Finished: Texture Black powder coated painted finish
- Support: Top pull rod to ensure stability
- Base: Heavy duty 180 degree swivel base with safety stop
- Base Connection: Duct Collar included for connection of central tube, bends and fittings which can be mount to the top or bottom of boom base. If duct collar is removed, the boom base bolt pattern will accept the mount of a 1HP (6” Boom) or 2HP Fan (8” Boom)
- Tubes: Spiral duct to minimize friction loss and static pressure
Optional Additions
- Backing plate with threaded rod and hardware for mounting boom to wall or post
Resources
Download product brochures, manuals, and watch instructional videos for this product.
