Product Details
Comprehensive information about this product
Application:
- 1 to 2 Tech Housekeeping Wet Mix Vacuum System
- 1 to 2 Tech Grinder Wet Mix Vacuum System
- 3 to 4 Tech Orbital Sander Wet Mix Vacuum System
Part Numbers:
- EIC-M05-1800400B: 5HP System
- EIC-M10-1800400B: 10HP System
- EIC-M15-2400400B: 15HP System
Equipment Specs:
- Construction/Finish: Carbon steel which is epoxy powder coat painted and treated with zinc oxide and rust inhibitor zinc primed and final powder coat finish
- Blower: Regenerative Blower set to run for 20,000+ hours of continuous use
- Filtration: Initial venturi entry for deep penetration into the water, secondary baffles to completely mix the dust particulate with the water and final stainless steel mesh descicant mist eliminator(s) (99% efficient at 5 micron)
- Water Level Indicator: Automatic level control via an ultra sonic probe situated in a reservoir of “quiet” water
- Relief Valve: Valve automatically opens when system is shut off to exhaust hydrogen gas build-up in an aluminum application
- Particulate Removal: Ball valve for removing the sludge
- Electrical: 208-240, 460 and 575 volts. 3 phase, 60 hertz Premium Efficiency TEFC Motor
- Inlet: 3”OD to 4”OD
PLC Control Panel Specs:
- NEMA 4 Enclosure (Indoor/Outdoor)
- Start/Stop
- Overload Protection
- Run Light
- Hour Meter
- 120v Step Down Transformer (ie: Control remote on/off switches)
- Automatic Water Fill
- Low or High Water Automatic Shut Off
- Provisions for venting gasses
- Fault Log
- Manual Control for diagnostic purposes
- Input and Output Status screens
- System Parameter Adjustments
- Fan Pressure and Amperage Monitor
- Differential Pressure Monitor
- User programmable run timer
System Performance
- 5HP System
- Vacuum – 100″WC
- Flow – 160 CFM
Optional Additions
- Stainless Steel Construction
- Hydrogen Relief Vent (For aluminum applications)
- 2 Micron Mist Eliminator
