Part Numbers:
- SPD-15C-00000000: EIV 15HP System (360 ICFM @12"Hg)
- SPD-20C-LP000000: EIV 20HP System (520 ICFM @12"Hg)
- SPD-20C-HP000000: EIV 20HP System (400 ICFM @16"Hg)
- SPD-25C-LP000000: EIV 25HP System (600 ICFM @12"Hg)
- SPD-25C-HP000000: EIV 25HP System (500 ICFM @16"Hg)
- SPD-30C-LP000000: EIV 30HP System (870 ICFM @10"Hg)
- SPD-30C-HP000000: EIV 30HP System (650 ICFM @16"Hg)
- SPD-40C-LP000000: EIV 40HP System (940 ICFM @12"Hg)
- SPD-40C-HP000000: EIV 40HP System (840 ICFM @16"Hg)
- SPD-50C-LP000000: EIV 50HP System (1310 ICFM @12"Hg)
- SPD-50C-HP000000: EIV 50HP System (1050 ICFM @16"Hg)
- SPD-60C-LP000000: EIV 60HP System (1850 ICFM @12"Hg)
- SPD-60C-MP000000: EIV 60HP System (1280 ICFM @14"Hg)
- SPD-60C-HP000000: EIV 60HP System (1200 ICFM @16"Hg)
- SPD-75C-LP000000: EIV 75HP System (2200 ICFM @12"Hg)
- SPD-75C-HP000000: EIV 75HP System (1550 ICFM @16"Hg)
Equipment Specs:
- Construction: Fully welded steel construction
- Finish: Texture Blue powder coated painted finish
- Blower: Rotary Positive Diplacment Blower with fabricated mild steel motor base, V-blt drive package and 4" inline filter with pressure differential gauge for dirty filter detection
- Blower Relief: 2" Spring type vacuum relief valve with bird screen
- Filtration: Cyclonic filter separator, after polyester cartridge filters (99.93% at 3 microns or larger) and final automatic pulse jet cleaning
- Canister: 30 to 55 Gallon
- Electrical: 208-240, 460 and 575 volts. 3 phase, 60 hertz Premium Efficiency TEFC Motor
- Inlet: 4"OD to 8"OD
Control Panel Specs:
- NEMA 4 Enclosure (Indoor/Outdoor)
- Start/Stop
- Overload protection
- Run Light
- 120v Step Down Transformer (ie: Control remote on/off switches)
- 24VDC Sequential On Demand Auto Pulse Jet. Includes Proportional Type “On Line” Cleaning, “Off Line” Cleaning
- Filter Differential Pressure (dp) Display
- Dirty Filter Fault Shutdown/Light (c/w external reset)
- General Pulse Jet Fault Light
Includes
- Silencer, 4 Anti Vibration Pads & Wedge Anchors
- Tube, Bends & Fittings Between Blower & Separator
- Air Filter Regulator (For Pulse Jet Cleaning)
Optional Additions
- Sound Attenuation Cabinet - For EIV 60HP High Pressure to 75HP (SPD-SOU-60HP7500)
- HEPA Filter Housing - For EIV 15HP to 30HP (SPD-HEP-15300000)
- HEPA Filter Housing - For EIV 40HP to 60HP (SPD-HEP-40600000)
- HEPA Filter Housing - For EIV 60HP High Pressure to 75HP (SPD-HEP-60HP7500)
- Sound Attenuation Cabinet - For EIV 15HP to 30HP (SPD-SOU-15300000)
- Sound Attenuation Cabinet - For EIV 40HP to 60HP (SPD-SOU-40600000)
