Product Overview

The EII 2.5HP Wet Mix Dust Collector is designed for demanding dust extraction operations with 1 to 2 technicians using source capture tools at the same time. Wet Mix Dust Collectors remove explosive dust by driving the particulate deep into the water via a venturi. Dust then passes through a set of baffles (entrapping the dust in water) which settles to the bottom of the collector. All systems meet NFPA and OSHA guidelines.

Product Details

Comprehensive information about this product

Application:

1 Tech Grinder Vacuum System
1 to 2 Tech Orbital Sander Vacuum System

Part Numbers:

SYS-050-18300000: EII Wet Mix Collector
SYS-050-18300300: EII Wet Mix Collector w/ Low Water Automatic Shut Down

Equipment Specs:

Construction: Fully welded stainless steel construction
Finish: Texture Blue powder coated painted finish
Blower: 2.5HP Brush Motor (4000 Hrs Intermittent Duty)
Filtration: Initial Venturi Entry (for deep penetration of dust into the water), Secondary Baffles (to help knock water/dust back down) and Final Mesh Mist Eliminator (99% efficient to 5 microns)
Controls (On/Off/Auto Switch): 3 Position Switch. Auto position will start and stop portable based on if pneumatic tool is in operation
Electrical: 115 Volt 1Ph 60Hz, 13.9 amp, 1512 Watt (US / Canada). Includes 15′ (4.55M) Electrical Cord
Manual Drain Valve: Includes Plastic Bucket
Water Level Indicator: Site Glass Indicates when Refill of Water is Required
Manual Water Intake Port
Relief Valve: Exhausts Hydrogen Gas Build-up in an Aluminum Application, when System is Shut Down
Inlets: Qty 2: 1-1/2″ Inlets
Dimensions: 26″W x 28″D x 62.5″H

System Performance:

Vacuum – 146.6″WC
Flow – 141.5 CFM

Includes

Qty 2 – 1-1/4″ to 1” x 20′ Hoses w/ Airline
Qty 2 – Hose Hangers
